CVM THUNDER 125 17/14

Description

Specifications

Specification Details
Engine Type 125cc, manual clutch (N-1-2-3-4), single-cylinder
Carburetor PZ26
Cooling Air-cooled
Transmission #428 chain drive
Ignition Kick start
Maximum Speed 75 km/h
Fuel Tank Capacity 3.2L
Front Wheel Steel rim, 70/100-17″ off-road tire
Rear Wheel Steel rim, 90/100-14″ off-road tire
Front Fork Hydraulic, non-adjustable, 770mm
Rear Suspension Hydraulic, adjustable rebound, 350mm
Brakes (Front/Rear) Front: Hand disc brake; Rear: Foot disc brake
Handlebar Steel, φ28mm
Frame Steel
Rear Swingarm Steel
Muffler Aluminum

Dimensions

Specification Details
Seat Height 850 mm
Wheelbase 1220 mm
Maximum Load 75 kg
Net/Gross Weight (N.W./G.W.) 77 kg / 90 kg
Ground Clearance 285 mm
Assembled Dimensions 1700 mm × 770 mm × 1050 mm
Packaging Dimensions 1440 mm × 380 mm × 760 mm
